CLASSIC XDC9500 WINCH

WARN



WARN CLASSIC WINCHES

Encompassing the Entry Level, Premium, Ultimate Performance and Heavyweight Series’, Warn’s classic winches are packed with features to keep you advancing in even the toughest terrain. With industry leading technology, Warn’s range of winches are designed for high performance and reliability to give you the pulling power you need, when you need it.

XDC9500

With a low profile and compact shape allowing it to fit a wide variety of applications, the Warn XDC9500 winch is versatile and reliable. An important feature of this model is the thermometric protection device which ensures long motor life by suspending winching if the operating temperature becomes too high. (Not available in the US)


SPECS:

  • Maximum Load – (Single Line) | 4320kgs (9,500 lbs)
  • Motor - 12V Gen II,4.6hp, series wound
  • Control - Remote switch, 3.7m lead
  • Gear Train - 3 stage planetary
  • Gear Ratio - 216:1
  • Clutch – (Freespooling) - Sliding ring gear
  • Cable - 30m x 8mm dia.
  • Brake - Automatic mechanical cone
  • Dimensions - L 55.5cm x D16cm x H19.3cm
  • Drum Diameter/Length - 6.4cm / 23cm
  • Weight- 39.5kgs

VIEW PERFORMANCE DATA


Enquire Here


SKU: XDC9500 TAGS: WARN CLASSIC WINCH, WINCHES, XDC9500
